The SM22 has a transparent resin layer on the magnet’s surface.This coating increases protection against shocks, scratches and external agents.
The magnetic NdFeB alloy’s adhesive force is further enhanced by the steel cup, ensuring high performance even in the smallest sizes.

This makes these magnets particularly popular in different industrial sectors, such as furniture, automation, advertising, furnishing elements, thermoplastic molding, industrial equipment, etc.

Contact us to get quick feedback on prices, availability and customized products.
You can view and download the technical drawings of each product by clicking on the respective code, highlighted in blue.

All measures are in millimeters (mm).

CODE D H THREAD M (F) STRENGTH KG
SM22.35NI00.1985 19 8 M5X4 6
SM22.35NI00.2010 20 10 M3X5.5 8
SM22.35NI00.3010 30 10 M6X7 13
SM22.35NI00.3816 38 10 M6X5 34
SM22.35NI00.5020 50 20 M8X8 85

The maximum standard operating temperature for resin-coated products is 60 °C.
On request, we can supply uncoated magnets capable of operating at higher temperatures, as indicated in the Materials Table.

Many of these sizes are also available in other variants, with different coatings and degrees of magnetization.

The force values given in the tables are the result of dynamometric tests performed with a 10 mm thick iron plate.
Any variations from this standard in the use may change the actual performance of the magnet.

It is always recommended to perform specific tests according to your application.
