Electromagnets
FIRE DOOR HOLDERS
ELECTROMAGNETS FOR FIRE DOORS FOR WALLS OR FLOORS
.png)
%20(7).png)
The S30060 electromagnets are designed with a robust plastic mounting base.
This model is ideal for ceiling, floor or wall installations, and it can be easily rotated. Height and length can be modify at will thanks to the accessory tube.
It is normally supplied with an S01 articulated counterplate. Moreover, it is equipped with a release button and a protection circuit.
The standard operating voltage is 24 V DC. With regard to the electrical connection, the power supply wires can enter from the bottom o laterally through special tear-off tabs.
Contact us to get quick feedback on prices, availability, variants, and accessories.
All measures are in millimeters (mm).
(1).png)
| CODE | A | B | C | D | E | F | G | H | I | L | M | WEIGHT KG |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| EMPT.S30060.105105122185 | 105 | 105 | 122 | 50 | 80 | 80 | 6,5X12 | 185 | 20 | 150-165 | 100 | 0,60 |
| EMPT.S30110.105105122196 | 105+5 | 105 | 122 | 60 | 80 | 80 | 6,5X12 | 196 | 20 | 150-165 | 100 | 0,85 |
Contact us for more information on voltage, force, current consumption (mA), protection circuit, and door status.
